Why Accuracy Claims Matter

At SHINING 3D, accuracy is not just a specification on paper — it is a commitment backed by standards, controlled testing environments, traceable reference tools, and full inspection before shipment. For more than 20 years, we have continuously worked to improve the accuracy and reliability of 3D scanning and measurement, ensuring that every device delivers trustworthy results in real-world use.

Key Points

1. Built on internationally recognized standards

SHINING 3D has established its testing system in accordance with internationally recognized standards such as VDI/VDE 2634 and ISO 10360-13. This ensures that the acceptance and reverification methods for optical 3D measurement systems are scientific, consistent, and globally recognized.

2. Stable and controlled testing environment

The production and quality inspection areas are equipped with isolated environments where temperature is maintained at 20°C ±0.5°C and humidity at 40%–60% RH. This minimizes the impact of environmental variables on accuracy testing and helps ensure highly stable measurement results.

3. High-precision reference tools with full traceability

All calibration artifacts, such as 1000 mm ball bars, are certified by high-precision coordinate measuring machines and regularly revalidated. With an accuracy of up to 2.4 μm + 2.8L/1000 μm, these reference tools ensure traceability and credibility in every measurement result.

4. Maximum-error evaluation across the full measuring range

Each device, such as the EinScan Rigil, undergoes five repeated measurements, and the maximum error value is used as the final basis for evaluation. SHINING 3D does not rely on average values or best-case results, ensuring that real-world performance will not fall below the stated accuracy specification.

5. 100% inspection before shipment

Unlike approaches based only on batch sampling, SHINING 3D performs accuracy verification on every single device before shipment. This ensures that every product delivered to customers provides real, reliable performance and avoids the risk of performance deviation between units.

This is how SHINING 3D turns accuracy from a claim into a measurable promise: through internationally recognized standards, rigorous environmental control, traceable calibration, maximum-error evaluation, and 100% pre-shipment inspection. It is this commitment that gives users greater confidence in the performance, consistency, and reliability of every SHINING 3D scanner.
